- Four sided, nickel plated jaws for clamping the majority of all edge cut/flat type keys. Smooth rotation by simply twisting into position.
- Slotted jaw surfaces accommodate tip stop bars and a rigid shoulder gauge design to allow for greater accuracy when loading and gauging keys.
- Wide spacing 3 1/2” (88.9 mm) spacing between clamps accommodate large bow (head) and long blade keys, including flip style keys.
- Depth tracer system with micro adjustment for precise calibration in increments of .00098”. (0.025mm)
- TiN (Titanium Nitride) coated cutter for longer life and oxidation resistance.
- Nylon deburring brush.
- Electro-magnetic “main” safety switch with a separate cutter motor switch for easy access.
- Large transparent cutter safety shield contains chips and provides a storage area for accessories.
- Large drawer-type swarf (chip) tray under the carriage for easy access.
- Mounting bracket included for securing the machine to counter.
- Two year manufacturer warranty.
We're here to help make your key machine purchase easy.
Key machines are not returnable, so please call us with any questions you may have prior to making your purchase.
- Power Supply: 120V-60Hz
- Maximum Absorbed Power: 2.8 Amp, 200 Watt
- Cutter Motor: single phase and speed
- Movements: by ball joint on rectified carriage
- Tool Speed: 1350 rpm
- Carriage Runs: 1.65” (42 mm)
- Cutter: TiN coated
- Brush: Nylon, 5/8” (15.87 mm) bristles
- Width: 15.75” (400 mm)
- Depth: 18.1” (460 mm)
- Height: 9.8” (250 mm)
- Weight: 31 lbs. (14 kg)
